Brand Name : Zaozhuang NO.1
Model Number : X6336P
Certification : CE,ISO
Place of Origin : Shandong, China
MOQ : 1 set
Price : 7700USD
Payment Terms : T/T
Supply Ability : 1000 sets/month
Delivery Time : 15 days after getting the deposit.
Packaging Details : Export standard wooden case or as customers' requirement
Table size(mm) : 1500x360
Table travel(mm) : 1000/360/450
Spindle Taper : ISO40
Spindle speed range(rpm) : 50HZ:65-4500 / 60HZ:80-5440
T-groove : 3-18x80
Distance between spindle nose and table surface(mm) : 140-590
Spindle motor power(kw) : 4
X6336P Turret Milling Machine Manual Multi Function Vertical Turret Milling Machine
This turret milling machine is capable of vertical and horizontal milling, drilling, boring, reaming, and other operations. The milling head is mounted on the front end of a rocker arm, capable of rotating ±45° forward and backward and ±90° left and right. The rocker arm can move forward and backward along the upper bed and rotate 360°. The machine's three-way guide rails are designed to be wear-resistant, ensuring high precision, stability, and a long service life.
Product features:
1.M Hanna high strength cast iron, internal honeycomb rib structure, high rigidity, long service life.
 2.Spindle adopts imported from Japan King combination diamond. After the quenching and tempering and frequency processing, after fine grinding with 4 imported bearings (other manufacturers spindle 3 bearing), ensure high quality and high precision.
 3.Three shaft screw fine grinding with advanced phosphor bronze nut, durable.
 4.Horizontal milling with 4 gear shaft speed (other manufacturers for the 2 gear shaft), a wide range of variable speed, torque.
 5.Many parts of the machine tools have been applied for patent
Standard Configuration:
Integrated Control Panel
X/Y automatic feed
Electric lift of Zaxis
Taiwan turret milling head
Three-axis rectangular guide rail
Optional Configuration:
electronic oil pump
dividing head
rotary table
tool
clamping kit
Three-axis DRO
pneumatic draw bar
Product specification:
Details Display:




|   |
| X6336P Turret Type Manual Milling Machine Universal 220V 380V Voltage Images |
